In order to meet the needs of users for high-pressure and high-flow electro-hydraulic directional valve products, Huade Hydraulic has developed the HD-WEH…-1X/ series electro-hydraulic directional valve products, which have higher performance indicators, stronger impact resistance, and a wider range of applications. They can be widely used in injection molding machines, shotcrete machines, metallurgy, engineering machinery and other industries.
For complete selection guidelines and cross-reference documentation on this product line, please consult our Rexroth replacement hydraulic products guide.
Product Features of electro-hydraulic directional valve HD-WEH…-1X
▶No end cap design, stronger impact resistance;
▶More convenient oil supply and discharge adjustment method;
▶Customized products can be provided;
▶More compact product structure, smaller installation space, lighter weight.
Parameter of electro-hydraulic directional valve HD-WEH…-1X
| Size | 16 | 25 | |
| Maximum working pressure P, A, B(bar) | 350 | ||
| Maximum working pressure T(bar) | External | 350 | 315 |
| Internal | 210 | ||
| Maximum working pressure Y(bar) | 160 | ||
| Maximum pilot pressure X(bar) | 315 | 260 | |
| Minimum pilot pressure (bar) | 14 | ||
| Maximum working flow(L/min) | 400 | 650 | |
| Working medium temperature | -20~+80 | ||
