Pressure Sequence Valve Rexroth Interchangeable

Pressure Sequence Valve DZ 10 DP

MANUFACTURER Genuine Huade Hydraulic
STANDARDS ISO 4401 / DIN 24340
AVAILABILITY Factory Direct Stock
Pressure Sequence Valve DZ 10 DP
TECHNICAL REPLACEMENT NOTICE

This Huade® directional control valve serves as a 100% direct drop-in replacement for Bosch Rexroth PRESSURE-SEQUENCE-VALVE-DZ-10-DP equivalents. Dimensions, mounting interfaces, and technical parameters are identical. Designed for cost reduction in industrial and mobile hydraulic systems.

• Product features: Direct operated design, Rexroth-compatible technology, subplate mounting with multiple adjustment options

• Specifications: DZ 10 DP series, inlet pressure up to 31.5 MPa, max flow 80 L/min, mineral oil/phosphate ester compatible

• Applications: Lifting machinery, construction equipment, industrial vehicles, machine tools, ships, and metallurgical systems

Request B2B Quote

Submit your target quantity and technical questions. Our hydraulic engineering team will provide a factory-direct quote and lead time estimate within 24 hours.

Send Product Inquiry → 📥 Download PDF Datasheet
💬 WhatsApp: +86-18217786775
✓
100% Genuine Huade Direct factory authorized supply
✓
ISO 4401 Mounting ISO 4401 / Rexroth interchangeable
✓
Secure Packaging Sealed rust-proof global shipping

Technical Data Sheet

  • Product Overview
  • Features & Applications
  • Technical Parameters

Product Overview

The pressure sequence valve type DZ 10 DP is a direct operated pressure sequence valve. It is used for pressure dependent sequencing of a second system. It is wildly sold in China and in foreign countries with high quality and lower price. Huade® pressure sequence valve fully complies with international standards in the hydraulic industry. By introducing advanced Rexroth technology, Huade® hydraulic valves are compatible with Rexroth in performance.

Mineral oil (for NBR seal),or phosphate ester (for FPM seal)

Fluid cleanliness Maximum permissible degree of contamination of the fluid to NAS 1638 Class 9

Key Features

  • For subplate mounting
  • 4 pressure ratings
  • 4 adjustment elements:
  • Rotary knob
  • Sleeve with hexagon and protective cap
  • Lockable rotary knob with scale
  • Rotary knob with scale
  • With pressure gauge connection
  • Check valve, optional
  • Mounting pattern to DIN 24 340, form D, ISO 5781 and CETOP - RP 121H

Industrial Applications

  • This pressure sequence valve DZ 10 DP can be widely used in hydraulic systems of lifting and transport machinery, construction machinery, industrial vehicles, machine tools, ships, metallurgy and other equipment.
  • The sequence pressure is set via the adjusting element(1).
  • The compression spring (2) holds the control spool (3) in the start position, the valve is closed. The pressure in port A is present at the piston area of the control spool (3) opposite to the compression spring (2) via the control line (4). When the pressure reaches the value set on compression spring (2), the control spool (3) is moved and opens the connection A to B.The system which is connected to port B is sequenced without the pressure in channel A falling.
  • The control signal is obtained via the control line (4) from port A or externally via connection X.
  • Depending on the valve application the leakage drain oil can be passed externally via connection Y or internally via B.
  • structure of DZ 10 DP 1 -40B
  • Symbols of DZ 10 DP-10B

Technical Parameters

Mechanical ratings and operating limits for the Pressure Sequence Valve DZ 10 DP:

Parameter / Dimension Name Value / Rating Specification
Technical Data Technical Data
Inlet pressure,port P, B (X） (MPa) up to 31.5
Outlet pressure,port A (MPa) to 21.0
Back pressure,port T  (MPa) to 16.0
Max.permissible flow (L/min) to 80
Fluids Mineral oil (for NBR seal),or phosphate ester (for FPM seal)
Viscosity range(mm ²/s) 10~800
Fluid temperature range(℃) -30 up to +80
Fluid cleanliness (um) Fluid cleanliness Maximum permissible degree of contamination of the fluid to NAS 1638 Class 9
Max.flow (L/min) up to 80
